- Type:SMD LED
- Place of Origin:CN;GUA
- Brand Name:YLL
- Power Dissipation:0.002
- Optical Attenuation(%):0.002
- Luminous Intensity:800-100mcd
- Storage Temperature(℃):0 - 40
- Emitting Color:Blue
- Operating Temperature(℃):-20 - 40
- Viewing Angle(°):120
- Certification:CE
- Certification:RoHS
- Color Temperature:465-470nm
- Luminous Flux(lm):5-8lm
- Model Number:2835 smd led
- Chip Material:InGaN
- Power:0.2w
led bar light dedicated epistar chip 2835 0.5w blue smd led
SOME OF THE PRODUCTS WO COULD CUSTOMIZED FOR CUSTOMERS’SPECIAL REQUIRTMENT.
2835 Products |
VF(V) |
IF(mA) | WL/CT (nm/K) | IV (mcd) | Lumen(lm) | Power (w) |
angle |
Ra |
red color | 2.0-2.4 | 150 | 620-630 | - | 10-12lm | 0.5 | 120° | _ |
Yellow color | 2.0-2.4 | 150 | 588-592 | - | 10-12lm | 0.5 | 120° | _ |
Blue color | 3.0-3.4 | 150 | 465-475 | - | 5-8lm | 0.5 | 120° | _ |
Green color | 3.0-3.4 | 150 | 515-525 | - | 14-16lm | 0.5 | 120° | _ |
white | 2.8-3.4 | 150 | 2800-3200 4000-4500 6000-6500 | _ | 45-55lm | 0.5 | 120° | 80-85 |
white | 2.8-3.4 | 150 | 6000-6500 | _ | 50-60lm | 0.5 | 120° | 80-85 |
C h a r a c t e r s :-Medium power,high brightness-Wide Bean Angle-Low impedance-High light efficiency
-Wide Emitting Light Area
A p p l i c a t i o n :-LED Tube-LED Panel Light-LED DownLight-LED Auto Light-LED bulb-LED backlight
1. What will be the delivery time ?
A: We have large quantities in stock for normal color size ,and for special color and size,it needs 3-5 days to customize.100k units is available for most of our products in normal color and size.
2. What will be the price terms ?
A: We can accept FOB,other terms we can discuss.
3. What will be the types of payment ?
A: The payments we can accept are L/C, T/T,Western Union,MoneyGram.
4. What is you chip brand ?
A :The chips we use usually are form American Cree and Taiwan Epistar .
![C}52{Q9I22$S6H1{E0VX]]9.jpg](http://sc02.alicdn.com/kf/HTB1MnUzIFXXXXcRXVXXq6xXFXXXo/220350597/HTB1MnUzIFXXXXcRXVXXq6xXFXXXo.jpg?imageMogr2/format/webp/auto-orient)
Our Advantage
1.Energy saving, low power consumption, compared with the traditional lamps and lanterns can save electricity 60% 80%;High evenness, adopts imported optical guide plate and the atomization quality board, can make the LED light can make full use of and evenly spread, in order to achieve high brightness uniformity characteristics;
2.Long life LED energysaving lamps use theoretical service life of up to tens of thousands of hours, the ordinary incandescent lamp using life over 1000 hours.
3.The green environmental protection does not contain harmful elements such as mercury and lead, thanks to recycling and utilization, and won't produce electromagnetic interference, ordinary tubes containing mercury and lead 1. Energy saving, low power consumption, compared with the traditional lamps and lanterns can save electricity 60% 80%;High evenness, adopts imported optical guide plate and the atomization quality board, can make the LED light can make full use of and evenly spread, in order to achieve high brightness uniformity characteristics;
Yuliang Growth History
Shenzhen Yuliang Optoelectronic Technology Co.,Ltd
In the Year 2001, the company founder Mr Shang Wuming established "Shenzhen Yuliang Optoelectronic Co.,ltd’ , at poineering initial stage, Yuliang company mainly engaged in LED lamp beads of domestic trade, successively established counters in Shenzhen Huaqiang electronic market, Baoan electronic digital market.
In the Year 2004, Yuliang Formally started the production, and the factory was located in dongquan new villiage Mingzhi,Longhua district,shenzhen, and changed its name to "Shenzhen YuLiang source electronic factory, mainly specialized in dip led, straw led, piranha LED , early has more than 30 employees, the monthly production capacity reached about 5 KK.
In the Year 2005,In May, Yuliang moved to the location Third Industry Area Bantian,Longgang distrcit,Shenzhen, Yuliang was the first to introduce full automatic production equipment such as full automatic solid crystal machines etc, and the mainly products are Piranha led, have 60 employees, and become one of the important manufactory in shenzhen for the Piranha LED.
In the Year 2007,in May, due to the development, Yuliang moved to HengChangRong Industrial area,DaLang Street,LongHua district,Shenzhen City. Yuliang insist to the high-end product line, Successively introduce Piranha LED full automatic solid crystal machine, full automatic soldering machine, full automatic Spectrophotometric color machine, the first one in shenzhen to have the full automatic piranha led sealing glue line, and become a medium packaging plant which have manufactory space 2000 square meters, and more than 100 employees,at the same time , our products obtain a series apperance invention patent,utility model patents, and passed the CE ROHS etc testing certificaitons.
In the Year 2008, Yuliang started to investigate and produce SMD, small trial production 3528 and 5050smd, at the same year,Yuliang introduced ERP System for divide the products and started to establish the foreign sales, and we do our best to spead our top products to all over the world.
In the Year 2009,Yuliang formally changed ites name to "Shenzhen YuLiang Optoelectric Technology Co., Ltd.", and obtain the general taxpayer qualification, the same year we established the cooperation relationship with Alibaba, made in China, global markets etc, and do great effort to promote our products to overseas.
In the Year 2010, LED Industry is under the rapid growth ! Yuliang held a series exhibitions all over china within 2years, Successively participated in Guangzhou led exhibition, Hong Kong Spring Lighting Fair, Shanghai International LED Expo, Beijing International LED exhibition etc International famous exhibitions, and become 2010Year Sponsor membership of Shanghai World Expo, and successfully obtained TUV factory inspection certification. 10 years, we signed a long-term cooperation agreement with EPISTAR, and become the mainland rare epistar agreement manufactory.
In the year 2011 , Yuliang successfully pass ISO9001:2008 quality management system certification, and received the honorary certificate, and our products passed the EU EN-62471 certification, at the same year, Yuliang Shanghai office set up.
In the year 2012, Yuliang successfully passed the national high-tech enterprises identified, at the end of the year 2012,Yuliang moved to over 6000square meters of new plant Building A1,Silicon Valley Power Industrial Park,Guiyue Road,Zhangge Village,Guanlan Town,Shenzhen City,China.
In the year 2013, Yuliang Estalibhed the independent packaging laboratories, and passed the U.S. Energy Star LM-80 certification, TUV certification, a variety of products obtain the appearance patents, utility model patents.
In the year 2014, thanks to all of our stuffs, Yuliang beclome a modern high-tech led enterprise, and become the priority light source supplier of LED for car/outdoor led light source.
In the year 2015, we embarked on a new journey, we strive to contribute our own strength to the human lighting.
Honesty is the best policy for long time business.Quality is the bridge between YLL and you.
